Ashcroft 14902.5 Dual-Scale Low-Pressure Gauge 0 to 10 psi and 0 to 70 kPa

Name: Ashcroft 14902.5 Dual-Scale Low-Pressure Gauge 0 to 10 psi and 0 to 70 kPa
Brand: Ashcroft
SKU: 6893012
Price: 62.40 USD
Availability: OutOfStock

Zoom Image

Representative image only.

Add to Compare

Ashcroft 14902.5 Dual-Scale Low-Pressure Gauge 0 to 10 psi and 0 to 70 kPa

Ashcroft | Mfr: 25-1490-A-02L-XTU-10#/KPA| Item: EW-68930-12

Effective low-pressure and low-vacuum response with diaphragm

True zero indication identifies damaged gauges increasing safety and ensuring accuracy ... READ MORE

$62.40USD / Each

$78.00USD / Each

Add To Cart

+ADD TO LIST

PRODUCT OPTIONS

See All 15 Items in this Product Family

Include Calibration Services

InnoCal A2LA ISO17025 Accredited Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

for an additional

$266.75USD / Each

InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

for an additional

$179.75USD / Each

Time to Re-Calibrate Your Instrument?
Learn more about our calibration services

Buy It Together

Current Item

Ashcroft 14902.5 Dual-Scale Low-Pressure Gauge 0 to 10 psi and 0 to 70 kPa

6893012

$62.40USD / Each

$78.00USD / Each

InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

1704010

$179.75USD / Each

Cole-Parmer High-Accuracy Digital Gauge, 0 to 500 psig, 4-Digit LCD

6834912

$246.50USD / Each

$290.00USD / Each

Total Price 488.65 ADD 3 ITEMS TO CART

Product Description

Key Features

True zero indication identifies damaged gauges increasing safety and ensuring accuracy
Built-in snubber minimizes rapid pressure fluctuations
1 year warranty

More About this Item

Gauges have brass socket, beryllium copper diaphragm capsule, painted steel case, and polycarbonate lens. Bottom connection is 1/4" NPT(M).

Specifications

Accuracy±2-1-2% (ANSI/ASME Grade A)
Dial Size (in)2.5
Dial Size (mm)64
Min Pressure (PSI)0
Max Pressure (PSI)10
Wetted MaterialsBeryllium copper, brass, polysulfone, RTV silicone
CasePolysulphone
Lens MaterialPolycarbonate
Process Connection1/4" NPT(M), lower
Unit Of Measurementpsi, kPa
Displayanalog dial
Media CompatibilityGases and liquids compatible with wetted materials
DescriptionDual-Scale Low-Pressure Gauge 0 to 10 psi and 0 to 70 kPa
Warranty1 year
