Ashcroft Utility Gauge, 0 to 100 psi, 2" Dial, Bottom Connection

Name: Ashcroft Utility Gauge, 0 to 100 psi, 2" Dial, Bottom Connection
Brand: Ashcroft
SKU: 6800304
Price: 14.24 USD
Availability: OutOfStock

Zoom Image

Representative image only.

Add to Compare

Ashcroft Utility Gauge, 0 to 100 psi, 2" Dial, Bottom Connection

Ashcroft | Mfr: 20-W-1005-H-01L-100#| Item: EW-68003-04

Ideal to measure water, hydraulic oil, or gas pressure

True zero indication identifies damaged gauges—increases safety and ensures accuracy ... READ MORE

$14.24USD / Each

$17.80USD / Each

Add To Cart

+ADD TO LIST

PRODUCT OPTIONS

See All 20 Items in this Product Family

Include Calibration Services

InnoCal A2LA ISO17025 Accredited Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

for an additional

$266.75USD / Each

InnoCal NIST-Traceable Calibration; Pressure/Vacuum Gauge, Accuracy ≤1%

for an additional

$179.75USD / Each

Time to Re-Calibrate Your Instrument?
Learn more about our calibration services

Product Description

Key Features

True zero indication identifies damaged gauges—increases safety and ensures accuracy
1 year warranty

More About this Item

Gauges include brass socket, soft-soldered phosphor bronze Bourdon tube, painted steel case, and polycarbonate lens.

Specifications

Accuracy±3-2-3% full-scale (ANSI/ASME Grade B)
Dial Size (in)2
Dial Size (mm)51
Min Pressure (PSI)0
Max Pressure (PSI)100
Min Temperature (° F)-40
Max Temperature (° F)150
Min Temperature (° C)-40
Max Temperature (DegreeC)66
Wetted MaterialsBrass, phosphor bronze
CaseSteel
Lens MaterialPolycarbonate
Process Connection1/8" NPT(M), lower
Unit Of Measurementpsi
DisplayAnalog dial
Media CompatibilityGases and liquids compatible with wetted materials
Description0 to 100 psi Utility Gauge, 2" Dial, Bottom Connection
Warranty1 year
